Better & Further
While preserving the proven strengths of the S Series, the S+ Series introduces an optimized frame structure that improves efficiency, grounding continuity, and sustainability.
Key features and advantages;
- Optimized and Seismic Certified Main Frame Design with the partially welded structure
- Cable-free earthing continuity accessed by unpainted depth profiles.
- Improved swing frame design with 3 mm thickness, eliminating the need of cage nuts
- Continuous grounding achieved through direct contact of unpainted surfaces on swing frame and cover plates, without the need for earthing cables.
- Reduced Installation Time and Labor
Protection class according to IEC 60 529: IP55
IK CODE: IK10
SURFACE TREATMENT: Nanoceramic coating
COATING: Ral 7035 wrinkle UV resistive polyester powder coating
LOCK: Polyamide handle with key, 3 points latch
HINGES: Corner hinges, zinc, powder coated 240° opening angle (130°/180° with stopper)
INSETS: Door earthing cable (1 piece for each door)
Trim Strip
Door Stopper
GTIP CODE: 8538.10.00.00.00
CERTIFICATES:
IEC 62208
IP55 Test
IK10 Test
IEC 60068 Seismic Zone 4 & ASTM 4169 Transportation Test
EAC Certificate
RED Certificate
DECLARATIONS:
CE Declaration of Conformity
