E SERIES

E SERIES
Control and Protection Enclosures

Lean engineering!



E series grants competitive advantage in planning and execution with reliable and selfproven 2mm modular structure.

The components of the structure support and carry each other without need of welding and additional corner component.

Modular internal structure provides convenience and flexibility to user, whether in applications with mounting plates or in fixed and swing frame applications.



Some advantages of E series;



* Flexible, adjustable swing and fixed frame positions with 25mm steps.
* Swing Frame load capacity up to 120 kg.
* Adjustable opening angles of swing frame from 130 to 180 degrees.
* Improved swing frame design allows mounting of 19’’ devices with up to 435 mm depth

Protection class according to IEC 60 529: IP41 / IP55

IK CODE: IK10

SURFACE TREATMENT: Nanoceramic coating

COATING: Ral 7035 wrinkle UV resistive polyester powder coating

LOCK: Polyamide handle with key, 4 points latch

HINGES: Hidden hinges, zinc coated. 130° opening angle

INSETS: Door earthing cable (1 piece for each door)

GTIP CODE: 8538.10.00.00.00


CERTIFICATES:

IEC 62208-TSE
IP55 Test
IK10 Test

IEC 60068-3-3 Seismic Test
GR63 Core Seismic Test
ASTM 4169-16 Transportation Test
EAC Certificate
RED Certificate

DECLARATIONS:

CE Declaration of Conformity

Salt Spray Test Report
