High Ingress Protection!
B series provides up to IP66 protection class as a standard which provides safety for internal equipments.
By adding canopy & plinth, “”indoor wall mounting type”” enclosures transforms in to “”outdoor floor mounted type””.
Simple installation and flexible cable entries with screwed type bottom and top plates.
Protection class according to IEC 60 529: IP66
IK CODE: IK10
SURFACE TREATMENT: Nanoceramic coating
COATING: Ral 7035 wrinkle UV resistive polyester powder coating
LOCK: Quarter Turn Lock with DB key
HINGES: Hidden hinges, zinc coated. 130° opening angle
INSETS: Door earthing cable (1 piece for each door)
GTIP CODE: 8538.10.00.00.00
CE Declaration of Conformity
